Description

gravel bike tyre clearance Splitfire Gravel Bike - Ti 57mm/29x2.25 Tire ClearancePre Sales Open Now with ETA of July 2026. Blackwater Bicycles Titanium Gravel Splitfire: Everything Bigger The Splitfire is a titanium gravel bike built for riders who want more room, more speed, and more versatility from one frame. With clearance for up to 700 x 57mm tires, short 419mm chainstays, UDH compatibility, and clearance for oversized chainrings, Splitfire blends backcountry capability with fast gravel efficiency. 57mm Maximum listed 700c

Pre-Sales Open Now with ETA of July 2026.
Blackwater Bicycles / Titanium Gravel

Splitfire:
Everything Bigger

The Splitfire is a titanium gravel bike built for riders who want more room, more speed, and more versatility from one frame. With clearance for up to 700 x 57mm tires, short 419mm chainstays, UDH compatibility, and clearance for oversized chainrings, Splitfire blends backcountry capability with fast-gravel efficiency.

57mm Maximum listed 700c tire clearance for rough gravel, mixed terrain, and adventure setups.
419mm Short chainstays keep the bike lively and responsive despite the massive tire clearance.
45/50 Adjustable fork offset options allow riders to tune trail and steering feel.
Tire Clearance

700 x 57mm or 29 x 2.25 capability.

Splitfire was created for riders who want the freedom to run big, confidence-inspiring tires without giving up the speed and fit of a performance gravel bike. Larger tires add comfort, traction, and stability on rough roads, loose gravel, and long backcountry routes.

More Traction A larger contact patch improves grip on loose, wet, and uneven surfaces.
More Comfort Higher tire volume allows lower pressure and helps reduce fatigue on long rides.
More Control Big tires add stability when descending, cornering, and riding loaded.
More Versatility Run fast gravel tires, monster-cross tires, or bikepacking-ready setups.
Why Splitfire Exists

Short stays. Big tires. Big chainrings.

The elevated driveside chainstay gives the Splitfire its defining advantage: room for large tires and large chainrings while keeping the rear end compact. That combination makes it equally at home on fast gravel rides, rough mixed-surface routes, and road-wheel swaps.

Elevated Chainstay

The driveside E-stay opens space at the tire and chainring junction, allowing a rare mix of tire volume, gearing clearance, and short chainstay handling.

UDH Compatible

A modern universal derailleur hanger platform simplifies replacement, improves drivetrain compatibility, and keeps the frame ready for current and future drivetrain standards.

T47 Threaded BB

The T47 threaded bottom bracket combines the serviceability of a threaded system with a larger shell diameter for stiffness, alignment, bearing support, and easy maintenance.

Geometry

Progressive gravel fit with tunable handling.

Splitfire geometry is designed around stability at speed, responsive acceleration, and multiple tire configurations. The result is a titanium gravel platform that can be built for fast mixed-surface riding, rough gravel, or long-distance adventure use.

Fit & Geometry

Measurement S
52cm
M
54cm
M/L
56cm
L
58cm
XL
60cm
Reach 380 390 400 405 415
Stack 560 575 595 615 630
Effective Top Tube 520 535 555 560 575
Seat Tube Length 459 480 500 525 540
Head Tube Length 115 130 150 170 185

Handling & Chassis

Measurement S
52cm
M
54cm
M/L
56cm
L
58cm
XL
60cm
Head Tube Angle 70° 71° 71° 71° 71.5°
Wheelbase 1022 1026 1044 1065 1079
Chainstay Length 419 419 419 419 419
BB Drop 80 80 80 80 80
Fork Offset 45 / 50 45 / 50 45 / 50 45 / 50 45 / 50

Trail Measurements

Tire Size S
52cm
M
54cm
M/L
56cm
L
58cm
XL
60cm
32mm Tire 78 / 73 72 / 67 72 / 67 72 / 67 69 / 63
45mm Tire 83 / 78 76 / 71 76 / 71 76 / 71 73 / 68
55mm Tire 87 / 81 80 / 75 80 / 75 80 / 75 76 / 71
Maximum Tire Clearance 700 x 57c 700 x 57c 700 x 57c 700 x 57c 700 x 57c
Maximum Chainring 44t / 54t 44t / 54t 44t / 54t 44t / 54t 44t / 54t
Axle Standard 12x100 / 12x142 12x100 / 12x142 12x100 / 12x142 12x100 / 12x142 12x100 / 12x142
All measurements are listed in millimeters unless otherwise noted. Trail values are shown as 45mm offset / 50mm offset. Larger tires increase trail and stability; the 50mm offset option quickens steering response.
Technical Specifications

Built around modern standards.

Splitfire combines titanium durability, modern drivetrain compatibility, internal routing options, flat-mount disc brakes, and large tire clearance into one highly versatile gravel platform.

Specifications

Frame Material
Titanium 3AL-2.5V, 12x142 thru-axle, flat-mount disc, threaded T47 BB, internal routing
Sizes
Small 52cm, Medium 54cm, Medium/Large 56cm, Large 58cm, Extra Large 60cm
Frame Weight
1750g +/- 2% size 56, no hardware
Headset
Integrated IS52 / IS52 internal drop-in
Seat Post Diameter
27.2mm
Bottom Bracket
T47 inboard bearing
Brake Mount
Flat mount
Rotor Compatibility
Front: 160/180, Rear: 140/160, adapters required
Axles
Front 12x100, Rear 12x142
Tire Range
Minimum 700 x 35c, maximum listed clearance 700 x 57c
Maximum Chainring
Direct mount / outer spider: 44t; inner spider: 54t
Frame Routing
Headset internal or downtube internal
Mounts
4 bottle mounts, top tube mounts, fender compatible
Wheel Size
700C
Warranty
Backed by a 5-Year Limited Warranty

Build your Splitfire.

Choose the frame, fork, finish, wheelset, drivetrain, and cockpit setup that fits the way you ride. For full builds or custom options, contact Blackwater Bicycles for a quote.

Request a Quote
